CKAS-8102T pressure/absolute pressure transmitter

Product Description

CKAS-8102T pressure/absolute pressure transmitter is a new product launched by our company for pressure/absolute pressure measurement based on the structure of CKAS-8102. This product inherits all the characteristics of CKAS-8102, simplifies the structure, The product has the outstanding advantages of small size, light weight and convenient installation.

CKAS-8102T adopts imported pressure sensor diaphragm box, which has good stability and high reliability.

The CKAS-8102T electronic circuit adopts analog and smart round card circuits, and has two output modes of analog 4~20mA and digital communication (HART protocol). The intelligent CKAS-8102T has temperature and pressure self-compensation, self-configuration, self-calibration, Self-diagnosis and other functions, and various factory parameters are backed up, and will not be lost under any circumstances.

Intelligent CKAS-8102T adopts HART protocol to communicate, and can communicate with any host computer or hand-held communicator using HART protocol.

CKAS-8102T type can be equipped with LCD liquid crystal head, and the digital display units include kPa, MPa, %, mA, m, mm, etc.

Features

Excellent performance, precision 0.15%, 0.3%

Range: [kPa~60MPaMeasurement Range:kPa~60MPa All stainless steel welded structure

Filling fluid: high temperature silicone oil

Process connection: M20X1.51/2NPT' or flange
